Cable tray roll forming machine

1,Forming processing Uncoiler-flatting-clamp&punchine-positioning.cutting-forming-collection2, equipment capacity The production line can produce many types of cable rack and other machinery products according to producing requirement.(steel coil width 60mm≤§≤860mm) producespeed:2.5-5M/min3, Continuous forming speed:10-15M/min Steel thickness:1-2mm Material :Q235 4, The production line divide into two operations:automatic &handle.It can work with linkage and subsection . 5, The whole equipment consists of uncoiler,ML-900 flatting device,JF-200punching,punching mould,servo-feeding device,guider,forming machine,cutting device,positioning device,collection table and electrical control.etc.
