Steel keel roll forming machine

Forming Technology Decoiler-Guide-Roll forming-Cutting-to-length-Recoiler Equipment structure It is make up of decoiler, guide rack, main frame, leverl, cutting-to-length, recoiler, electrical system etc. Unit Performance 1,Machine capacity:width≤150mm,thickness0.6-1.2mm 2,Speed line:20-25M/min 3,Total power: About 5.5kw 4,Occupy ground area:length15M X width2.5MGeneral structure of equipment1 ,De-coiler 1.1 Parameter: width of material: 50200mm thickness: 0.61.2mm1.2 Inner diameter of coil: φ508mminner expansion range: 480-520 mm1.3 Outer max. diameter: φ1500mm; Max. loading: ≤2T1.4 Feeding speed: 20-25m/min, 2,Guider rack: one pair of lever roller and pairs of stand rollers. 3, Forming machine3.1 Type:GY120,Forming station: 12sets 3.2 Material max. width: 200mm 3.3 Material max. thickness: ≤1.2mm 3.4 The diameter of the roller axis: 50mm 3.5 Roll mould material: Gcr15,Quenching treatment,HRC58-62° 3.6 Drive type: 7.5kw frequency conversion electromotor. autocephaly distribute gear case 3.7 Mould: combination type 1set 3.8 Assistant roller rack:3 sets 3.9Adjust part: Turky emendation type (three-dimensional emendation) 4,Cutting-to-length device 4.1 Hydraulic blade cutting, it can be exchanged 4.2 Cutting manner: 45ºinclined cutting 4.3 Hydraulic station: 4KW
